Index Braille BASIC - Front Panel

Index Basic Servicemanual v 3.0
28
BOX 155 • S-954 23 GAMMELSTAD • SWEDEN • PHONE +46-920 203080 • TELEFAX +46-920 203085 • www.indexbraille.com • E-MAIL info@indexbraille.com
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
PIN 6
PIN 7
PIN 8
PIN 9
GROUP
SW01
1
SW09
NORMAL
SW08
ON LINE
SW16
SETUP
SW04
A
SW10
Z-FOLDING
SW14
FORMFEED
SW17
ITEM
SW03
10
SW11
SPLIT PAGE
SW15
SINGLE-
DOUBLE
SW19
VALUE
SW05
MULTIPLE
SW07
REPEAT
SW06
HELP
SW18
C
SW02
B
SW13
REFORM
SW12
OFF LINE
SW20
X1. PIN 6
X2. PIN 3
X3. PIN 2
X4. PIN 1
Y1. PIN 9
Y2. PIN 8
Y3. PIN 7
Y4. PIN 5
Y5. PIN 4
Front panel
