Index Braille BASIC - Stabilize the Printinghead Motor

Index Basic Servicemanual v 3.0
30
BOX 155 • S-954 23 GAMMELSTAD • SWEDEN • PHONE +46-920 203080 • TELEFAX +46-920 203085 • www.indexbraille.com • E-MAIL info@indexbraille.com
Stabilize the Printinghead motor
(old Basic up to serialno: 21400, approx)
31023
13040
2.6 mm
32055
32012
ST 3.5x32
Note! Remove Mainboard
before drilling the hole
