12
Setup
Child Car Seat
IMPORTANT
!
Do not use the restraint with harness shoulder
straps set at different heights.
Ensure that all straps have been secured
correctly by pulling on each strap.
Ensure that the harness straps are not twisted.
Always adjust the height of the shoulder straps
as the child grows.
Step 4:
Thread each shoulder harness strap back onto the
“G” connecting plate through the gate (see Figure 3).
The shoulder harness straps are connected to the
“G” connecting plate (see Figure 2).
Shoulder Slot Height
Step 3:
Push the ends of the shoulder harness straps
through the appropriate shoulder slot holes in the
cover and seat body for the child’s shoulder height.
(see above for correct shoulder height for forward
facing).
Having selecting the most appropriate shoulder
strap slots. Reverse the removal process.
Figure 2
Figure 4
Figure 3
PULL
Figure 5
To Next Page
