Remove & Replace Covers
Main Cover
Step 2:
Step 1:
BASE COVER:
TO REPLACE COVERS REVERSE THE ABOVE PROCEDURE.
BACKREST COVER:
Disengage buckle and tongues.
Step 3:
Step 1:
Step 2:
Step 3:
Do Step 1 from “To Remove Harness”.
Unclip the four press studs at the bottom of the cover and disconnect the two elastic loops
located at the top of cover (rear).
Remove Backrest Cover.
To remove and replace covers
Step 1:
Step 2:
Disengage buckle tongues from the buckle.
Step 3: Pass the three bar slide located below the
thigh harness slots on the end of each body/
slots. Each side of harness is now removed.
(see Figure 2).
Step 4: To release the buckle / crotch strap pass the
three bar slides attached through the crotch
slot holes in seat section (see Figure 3).
To Remove Harness
Step 1:
Step 2:
Step 3:
Step 4:
To Replace Harness
Figure 1
shoulder straps through the thigh harness
Disengage shoulder straps from “G” connecting
plates as shown on page 12 (refer to section
“Shoulder Slot Height” - Step 1 & 2).
Connect the buckle/crotch strap by feeding
the three bar slides on the crotch strap through
the holes in seat section (see Figure 3).
Reconnect shoulder straps to “G” connecting plate
as shown on page 12 (refer to section “Shoulder
Slot Height” - Step 3 & 4).
Engage the buckle tongues in the buckle.
Feed the lap end of the harness and the three
bar slide through the thigh slots (see Figure 1 & 2).
Figure 2
Figure 3
Push the buckle through the crotch slot in the cover.
Unclip the four press studs and remove Base Cover.
