The correct height for the shoulder straps is very
important for the optimum performance of the
restraint. The shoulder strap slots used in forward
facing position are the upper and middle positions.
The shoulder strap slots used in Child Seat mode are
above the lower shoulder height markers (refer Pages
29 & 30).
IMPORTANT
!
The shoulder straps must be in the slots which
are nearest to the child’s shoulders, but not
more than 25mm below the child’s shoulders.
Correct shoulder height
FRONT OF
VEHICLE
25mm
Determine whether your child requires the additional padding provided with this restraint, to
ensure a safe and snug t in the restarint. Refer to page 6 for suggested padding combinations.
Selection of appropriate padding combinations
Set Up
Child Car Seat
Shoulder Slot Height
From the rear of the restraint, remove each shoulder
harness through the gates in the “G” connecting
plate (see Figures 1, 2, 3 & 4).
Step 1:
With the child correctly sitting in the restraint, check
which set of slots (in the plastic shell of the restraint)
are the level with but not more than 25mm below the
child’s shoulders.
Step 2:
Pull the shoulder harness straps through the
shoulder slot holes in the seat body and cover.
They are now loose in the front of the seat.
Step 1:
Figure 1
