17
Use
Child Car Seat
Using Inbuilt Harness
Figure 1
PULL TO
LENGTHEN
PULL TO
LENGTHEN
Harness
Adjuster
“LIFT” TO
LENGTHEN
Step 1:
Step 2:
Step 3:
Ensure the restraint has been installed and set up as
per “Set Up” and “Installation” (refer Page 11 - 16).
To lengthen the harness “LIFT” the harness adjuster
(refer Figure 1) whilst grasping both shoulder harness
straps and pulling.
Ensure shoulder straps are pulled equally on each
side.
Place child in car seat with legs either side of the
buckle, place harness over the shoulders and hips.
(refer Figure 2).
Figure 2
To Next Page
