13
Installation
Child Car Seat
Step 1:
Installing Using Vehicle Seatbelt
IMPORTANT
!
Ensure that you use the
FORWARD-FACING BELT PATH
FORWARD
FACING
BELT PATH
Figure 1
Figure 2
Fold the rear of seat base cover and foam forward
to expose the seating surface of the base (refer
Figure 4).
Fully extend the seat belt and pass the lap and sash
sections of the vehicle belt under the rst armrest,
across the seat base ensuring you pass the seat belt
beneath the tongue in the plastic moulding (refer
Figure 4 & 5) then under the second armrest,
“CLICK” the buckle tongue into the buckle (Refer to
Figure 2, 3, 4 & 5).
Important notes: The vehicle belt is now located
across the seat base. The belt path is shown by the
arrows in Figure 4 & 5.
Step 2:
Figure 3
Place the restraint with the back against the back of
the vehicle seat, directly in line with the anchorage
point (refer Figure 1).
