14
Installing Using Vehicle Seatbelt
Installation
Child Car Seat
Always use Top Tether strap to attach the
child restraint to the vehicle.
Do not use the restraint without the Top Tether
strap correctly attached and adjusted.
Do not use on any vehicle seat which faces
sideways or rearwards.
IF AN AIRBAG IS FITTED IN THE SEATING
POSITION WHERE THE CHILD RESTRAINT
IS TO BE FITTED, FOLLOW THE VEHICLE
MANUFACTURER’S WARNINGS AND
INSTRUCTIONS.
WARNING
!
Pull sash section up
firmly before placing
Safe Grip (red belt clamp)
in position
Sash section
of vehicle belt
PRESS SEAT
BASE HERE
Figure 7
Figure 6
Tighten
sash belt
across base
REMOVE ALL
SLACK FROM
SEATBELT
Figure 4
Figure 5
Push down on the base of the restraint (with knee or
hand) whilst pulling the sash section of the vehicle
belt rmly up in direction of the yellow arrow in
gure 6. This will make the lap belt very tight across
the seat base. Whilst continuing to pull the sash
section up (i.e maintaining tightness of the lap
section). Tighten sash section of belt across the
base (refer Figure 7).
Step 3:
IMPORTANT
!
Ensure that you use the
FORWARD-FACING BELT PATH
FORWARD-FACING
BELT PATH
THREAD BELT
BENEATH THIS TONGUE
TONGUE
IN PLASTIC
MOULDING
Tongue
Seat cover
& foam
folded back
TONGUE
IN PLASTIC
MOULDING
Lap and
sash belt
pass across
the seating
surface of
the base.
To Next Page
