16
Setup
Infant Seat
• IF THE CHILD’S SHOULDERS TOUCH THE BOTTOM EDGES OF THE
HEADREST SIDE WINGS, RAISE THE HEADREST TO THE NEXT HEADREST
POSITION.
• THIS CHILD RESTRAINT DOES NOT REQUIRE THE STRAPS TO BE
DISCONNECTED TO ADJUST THEIR HEIGHT, ONLY THE HEADREST NEEDS TO
BE MOVED TO ADJUST THE SHOULDER STRAP POSITIONS.
IMPORTANT
!
ENSURE THE HARNESS STRAPS ARE ALWAYS
THREADED THROUGH THE HEADREST.
IMPORTANT
!
Correct tment of the harness is very important as it
restrains the child in the restraint. The harness must
t rmly around the upper torso of the child and be
positioned to ensure the the child’s arms and legs
are free.
Headrest & harness strap height adjustment cont...
Shoulder Height
The correct height for the shoulder straps is very
important for the optimum performance of the
restraint.
With the child correctly sitting in the restraint, check which set of slots (In the plastic shell of
the restraint) are level with or just above the infant’s shoulders.
If the harness straps are located in those slots, then the you can proceed with using the
restraint (see section “USE” on page 22). If not then adjust the shoulder straps. Refer to
“Shoulder slot height”.
IMPORTANT
!
The shoulder straps must be in the slots which
are nearest to the child’s shoulders, but not
lower than the child’s shoulders.
U
Figure 1
Front of vehicle
