Infasecure CS8113 - Remove & Replace Covers

45
Remove & Replace Covers
Main Cover
Figure 4
1
2
Figure 2
HARNESS
STRAPS
METAL
SPREADER
PULL
Figure 3
Step 1:
Step 2:
Step 3:
Figure 1
HARNESS
STRAPS
Step 4:
Step 5:
Step 6:
Unclip the press studs located;
back of seat
both sides of restraint
Remove cover
*Replace in reverse.
1
2
Loosen harness to allow spreader plate to
rise from under the restraint. Turn the restraint
so that the back of the seat is facing you.
Remove each shoulder harness through the
gates in the spreader plate (see Figure 1 & 4).
Pull the shoulder harness straps through the
shoulder slot holes in the seat body and
cover. They are now loose in the front of the
seat.
