39
Figure 1
PULL TO
LENGTHEN
PULL TO
LENGTHEN
Harness
Adjuster
“LIFT” TO
Figure 2
Use
Child Car Seat
Using Inbuilt Harness
LENGTHEN
Step 1:
Step 2:
Step 3:
Ensure the restraint has been set up and installed as
per “Set Up” and “Installation” (refer Page 31 - 38).
To lengthen the harness “LIFT” the harness adjuster
(refer Figure 1) whilst grasping both shoulder harness
straps and pulling. Ensure shoulder straps are pulled
equally on each side.
Place child in car seat with legs either side of the
buckle, place harness over the shoulders and hips.
(refer Figure 2).
IMPORTANT
!
KEEP BUCKLE LOW AS POSSIBLE
Always ensure buckle has clearance from the
upper thighs (see indicated area Figure 3).
Figure 3
To Next Page
