41
Figure 1
Figure 7
PINCH
TEST
Step 1:
To Release Child
To release your child from the restraint simply press
the harness buckle and carefully remove your child
from the restraint (refer Figure 1).
Use
Child Car Seat
Using in-built harness
IMPORTANT
!
A LOOSE HARNESS IS DANGEROUS.
provide extra support and comfort for small
babies. Discontinue use when the insert is a
babies/children.
Always adjust the height of the shoulder straps
as the child grows.
Step 3:
Adjusting Recline Angle
NOTE: To adjust the recline angle of the child seat
refer to “Converting to Child Seat” on page 31.
First loosen the seatbelt assembly, the Safe Grip Belt
Clamp may need to be removed.
At the front of the restraint is a red lever. Pull red lever
forward and slide the seat to obtain the desired
upright or reclined angle (refer Figure 1).
Reinstall the seatbelt and Safe Grip Belt Clamp
(refer Page 37).
Recline
Upright
RED
LEVER
Front
of Car
Figure 1
Check the harness tightness by the PINCH TEST ,
this is acheived by pinching the harness webbing at
the shoulders (refer Figure 7)
• If you can pinch the harness strap, tighten more.
• If your ngers slip off, then the harness is tight
enough.
If required repeat Step 5.
Step 6:
Step 1:
Step 2:
