40
Figure 6
Harness
Adjuster Strap
Using Inbuilt Harness
IMPORTANT
!
If no “Click” can be heard or a secure engagement
cannot be achieved refer to Cleaning Buckle
Harness page 44.
Use
Child Car Seat
“CLICK”
Figure 4
Figure 5
1
2
DO NOT LEAVE CHILDREN
UNATTENDED IN THE CAR.
A LOOSE RESTRAINT OR HARNESS
IS DANGEROUS.
WARNINGS
!
Remove all of the slack for the harness lap straps by
pulling shoulder straps (refer Figure 5), then pull the
harness adjustment strap to adjust harness to a
Step 5:
PULL TO
TIGHTEN
Step 4:
Insert either tongue into the buckle followed by the
other tongue until a “CLICK” is heard. Should the
second tongue not insert, press the red button and
reinsert the tongues. Ensure secure engagement by
pulling the harness strap (refer Figure 4).
comfortable but rm t (refer to Figure 5 & 6).
REMOVE ALL
SLACK FROM
HARNESS
To Next Page
