Shoulder height markers may
be hidden under a pillow
IMPORTANT
!
If so ring (02) 4728 8090 for nearest supply location (Refer page 45).
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
Child Car Seat
Model CS8113
1
2
3
4
5
6
7
8
9
14
13
12
11
Forward facing
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 43.
1. Shoulder Height Markers
2. Headrest Assembly
3.
4.
“TWIST & LIFT”
Headrest + Harness adjustment system
Comfort Cover
5. Shoulder Pads
6. Harness Straps
7. Buckle Pad
8. Padded Insert (if fitted)
9. Harness Adjuster
10. Harness Adjustment Strap
10. Comfort Covers
11. Vehicle Seat belt
12. Safe Grip Red Belt Clamp (if supplied with restraint)
13. “FORWARD-FACING SEAT BELT PATH” Marker
(each side of restraint - coloured yellow)
14. Top Tether Assembly
• Tether Strap
• Adjuster
• Attachment Clip
• Anchor Fitting + Attachment Hardware
10
To Next Page
