32
Setup
Child Car Seat
Step 1:
Step 2:
Step 3:
Step 4:
To adjust the headrest, lift the “TWIST & LIFT” ap
on the headrest cover. Turn the red “TWIST & LIFT”
knob clockwise to unlock the headrest (refer Figure 1).
Lift up or push down the headrest so that the
shoulder strap slots are level with or slightly above
your child’s shoulders. If the headrest is just above
the shoulders then the harness level will be correct
(refer Figure 2).
Release “TWIST & LIFT” knob so that it locks into
position. Ensure that it has locked in position by
gently pushing down on the headrest.
Loosen the harness straps before adjusting the
headrest.
You do not need to remove the restraint from
the vehicle to adjust the harness or headrest
positions.
IMPORTANT
!
For comfort ensure the bottom edges of the
headrest are not contacting the child’s shoulders.
When lowering the headrest ensure the headrest
apron does not bunch up behind the childs neck.
Figure 1
Headrest & harness strap height adjustment
Figure 2
