Infant Seat
VIEW A
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 46.
1. Shoulder Height Markers
2. Headrest Assembly
3. “TWIST & LIFT”
Headrest + Harness adjustment system
4. Shoulder Pads
5. Harness Straps
6. Buckle Pad
7. Padded Insert (if fitted)
8. Harness Adjuster
9. Harness Adjustment Strap
10. Comfort Cover
11. Vehicle Seat belt
12. Safe Grip Red Belt Clamp (if supplied with restraint)
13. “REARWARD-FACING SEAT BELT PATH” Marker
(each side of restraint - coloured blue)
14. Top Tether Assembly
• Tether Strap
• Adjuster
• Attachment Clip
• Anchor Fitting + Attachment Hardware
15. Top Tether Guide
