Place the child restraint in desired upright or reclined
position, with the back against the back of the vehicle
seat, directly in line with the anchorage point (refer
Figure 1).
Install the upper anchorage tting as shown on page
32 & 33 of these instructions (if required)
Figure 1
Hook the attachment clip to the anchor tting. Ensure
there are no twists in the upper anchorage strap (refer
Figure 2).
Pull to tighten to remove all the slack, from the upper
anchorage strap. Do not overtighten as this could
cause the restraint to lift off the vehicle seat (refer
Figure 3)
Figure 2
ADJUSTER
ATTACH
PULL TO
TIGHTEN
Tilt
Pull to
lengthen
Pull to
tighten
Figure 3
Always secure the loose end of the top tether
strap to prevent it hanging out of the car or
being accessible by the child.
Do not use the restraint without the top tether
strap correctly attached and adjusted.
Do not use on any vehicle seat which faces
sideways or rearwards.
IF AN AIRBAG IS FITTED IN THE SEATING
POSITION WHERE THE CHILD RESTRAINT
IS TO BE FITTED, FOLLOW THE VEHICLE
MANUFACTURER’S WARNINGS AND
INSTRUCTIONS.
Fit the restraint rmly to the car seat.
THIS RESTRAINT IS NOT SUITABLE FOR
USE WHERE TOP TETHER STRAP MAY FALL
INTO A SPLIT IN THE SEAT BACK OR OFF
THE SIDE OF THE SEAT.
CAUTION: CHILDREN CAN BE INJURED OR RESTRAINTS AND
TOP TETHER STRAP DAMAGED BY UNSECURED CARGO IN A
COLLISION. SECURE OR REMOVE HAZARDOUS CARGO
BEFORE USING THIS CHILD RESTRAINT.
Installation
Installing in vehicle (using lap-sash seat belt)
WARNINGS
!
SECTION
Child Car Seat
WITH INBUILT HARNESS
14
