Infasecure CS9013 - Backrest; Extension Straps

4
4
Replace Covers
Backrest
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Raise the headrest to highest position to access
press studs.
Slide the cover over the seatback and behind the
headrest (refer Figure 4).
Clip the press studs location (refer Figure 5).
NOTE: press studs may be obscured by headrest.
Clip the press studs located;
inside
outside
Attach the hook & loop connector located below
the headrest/apron and secure the cover (refer
Figure 5).
2
3
1
1
2
3
Figure 5
Figure 4
TYPE G
CHILD SEAT
EXTENSION
STRAP
Extension Straps
If required contact InfaSecure for nearest supply location. Extension straps, not
incuded in this package, may be required for vehicles without a xed parcel shelf.
TOP TETHER
STRAP
Re order line numbers
CS111 300mm Length
CS112 600mm Length
CS113 200 - 900mm
Adjustable Length
HOOK & LOOP
CONNECTOR
