Ensure the restraint has been installed and set up as
per “Set Up” and “Installation” (refer Page 11 - 16)
To lengthen the harness “LIFT” the harness adjuster
(A) (refer Figure 1) whilst grasping both shoulder
harness straps and pulling. Ensure shoulder straps
are pulled equally on each side.
Place child in car seat with legs either side of the
buckle, place harness over the shoulders and hips.
Insert either tongue into the buckle followed by the
other tongue until a “CLICK” is heard. Should the
second tongue not insert, press the red button and
reinsert the tongues. Ensure secure engagement by
pulling the harness strap (refer Figure 2).
Step 1:
Remove all of the slack for the harness lap straps by
pulling shoulder straps, then pull the harness
adjustment strap to adjust harness to a comfortable
but rm t (refer Figure 4).
Step 5:
Step 2:
Step 3:
Step 4:
Harness
adjuster (A)
“LIFT” TO
LENGTHEN
PULL TO
LENGTHEN
PULL TO
LENGTHEN
Use
Using in-built harness
“CLICK”
Figure 2
Figure 3
Figure 1
IMPORTANT
!
If no “Click” can be heard or a secure engagement
cannot be achieved refer to Cleaning Buckle
Harness page 20.
SECTION
Child Car Seat
WITH INBUILT HARNESS
17
