Step 12:
Step 13:
Step 14:
Figure 8
Cleaning
RIGHT Buckle slot
2
1
Figure 9
LEFT Buckle slot
LEFT slot
RIGHT slot
21
From the underside of the restraint pull the Buckle
adjusting plate then turn and push the plate up through
the centre slot (refer Figure 8).
From the underside of the restraint replace the small
screw securing the 3-bar plate (refer Figure 10) .
From the underside of the restraint replace the
inspection plate (6 x screws) (refer Figure 11).
Harness Buckle
Figure 11
Figure 10
