SHOULDER PADS (if tted)
Step 5:
Step 6:
Step 7:
Step 8:
SPREADER
PLATE
Raise the headrest to the highest position.
Note: Shoulder slots in headrest align with
slots in backrest (refer Figure 4).
Pass the shoulder straps through the slots of
the headrest and backrest. Harness straps
should protrude though the back of the
restraint (refer Figure 5).
Rethread the shoulder straps behind the
back cover plate (refer Figure 6).
Reconnect the shoulder straps through the
gates in the spreader plate (refer Figure 7).
Figure 7
HARNESS
STRAPS
SPREADER
PLATE
Figure 5
Accessories
Figure 6
Figure 4
