User Manual 7-13 V2.1
TriBoard TC3X9 TH V2.0(1) and TriBoard TC3X9 V2.0 2017-11
TriBoard Manual TC3X9
Hardware: TriBoard TC3X9 TH V2.0(1) and TriBoard TC3X9 V2.0
Schematic and Layout
Figure 7-12 Dimensioning (mil)
The dimensioning is valid for all TriBoards.
TriBoard-TC3X9 (TH) V2.0(1)
