XENSIV™ 60GHz BGT60TR13C Radar System on Module MCU4
Presence Detection
Presence event output
5 Presence event output
When event control is turned on, the presence detection result would be shown under the “Event” tab.
Item
Description
Presence
e
vent
Presence detection result.
In: Moving object detected in the zone.
Out: No moving object detected in the zone.
Distance (m)
Detected distance range of the closest moving object, in meter
s
.
Time (s)
Relative
event time, in seconds. The time starts from power on
;
it is not
an absolute time.
The received event command would be shown in the command text box for reference. When calibration mode
is enabled, a calibrate message box would also be shown.
Figure 8 Presence detect event page
