3. PRINTER FUNCTIONS
KPM210/216
163-
• The user-defined character definitions are cleared when:
ESC @ or
GS * or
ESC ? are executed or the printer is reset or the power shut
off.
[Default] Internal character set.
[Reference] ESC %, ESC ?
[Example]
HnLnv(CSEHnLnv(CSE
HnLnv(CSE
HnLnv(CSEHnLnv(CSE
[Name] Set relative vertical print position
[Format] ASCII ESC ( v nL nH
Hex 1B 28 76 nL nH
Decimal 27 10 118 nL nH
[Range] 0 ≤ nL ≤ 255
0 ≤ nH ≤ 255
[Description] Sets the print vertical position based on the current position
by using the horizontal or vertical motion unit.
• This command sets the distance from the current position
to [( nL + nH x 256) x ( horizontal or vertical motion unit)].
[Notes] • When the starting position is specified by N motion unit to
the bottom :
nL + nH x 256 = N
When the starting position is specified by N motion unit to the
top (negative direction), use the complement of 65536 :
nL + nH x 256 = 65536 - N
18 dots (11 cpi)
13 dots (15 cpi)
10 dots (20 cpi)
(Tab.A.3)
