3. PRINTER FUNCTIONS
KPM210/216
363-
HnLn²CSEHnLn²CSE
HnLn²CSE
HnLn²CSEHnLn²CSE
[Name] Receive graphic page from communication port
[Format] ASCII ESC ² nL nH
Hex 1B FD nL nH
Decimal 27 253 nL nH
[Range] 0 ≤ nL, nH ≤ 255
[Description] Receives [nL + (nH × 256)] words from the port and puts
them into the ram bank.
[Notes] • The number of data bytes received is [nL + (nH × 256)] × 2.
• Each word is first received as MSByte and then as LSByte.
• If [nL + (nH × 256)] is greater than 32768, the data which
follows is processed as normal data.
•The flash bank dimensions for the graphic print are :
with 204 dpi model have 1664 horizontals dots (208 bytes/
dot line) x 315 verticals dots (65312 bytes).
with 300 dpi model have 2464 horizontals dots (308 bytes/
dot line) x 212 verticals dots (65296 bytes).
•if the logo height is smaller than the maximum height of 816
pixel, the area not used is deleted.
[Default]
[Reference] ESC ·, ESC ³, ESC ¦
[Example]
n¦CSEn¦CSE
n¦CSE
n¦CSEn¦CSE
[Name] Transfer graphic page into flash bank
[Format] ASCII ESC ¦ n
Hex 1B FE n
Decimal 27 254 n
[Range] n = 1
[Description] Transfers the graphic page used at the moment into the flash
bank .
n selects the bank as follows:
nnoitcnuF
1hsalfotnitnemomehttadesuegapcihpargsrefsnarT
1ogolknab
(Tab.A.3)
