Infinity 310a - Electrical Parts List

FET-00-00045 F.E.T MUTTING J-FET J108 Q82,151 2
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP KTA1023Y Q01,173,174,175 4
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN KTC1027Y Q163,164,165,171 4
TRS-00-00091 TRANSISTOR SMALL SIGNAL PNP KTA1268GR Q22,154,155,161,162 5
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR Q152,153,156,187 4
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP KTA1266GR Q11,12,23,33 4
TRS-00-00110 TRANSISTOR SMALL SIGNAL NPN KTC3198GR Q02,90,198,199,219 5
TRS-00-00109 TRANSISTOR SMALL SIGNAL NPN KTC3198BL Q21 1
DIO-00-00108 DIODE FAST RECOVERY FR154 D51,52,53,54 4
DIO-00-00003 DIODE RECTIFIER IN4004 D02 1
DIO-00-00006 DIODE SWITCHING SIGNAL 1SS133 /1N4148 D03,04,11,80,81,151,152,160,161,169 11
D187
RES-00-00549 RESISTOR METAL FILM 1/5WF 510 OHM R214 1
RES-00-00586 RESISTOR METAL FILM 1/5WF 820 OHM R210 1
RES-00-00590 RESISTOR METAL FILM 1/5WF 910 OHM R157 1
RES-00-00482 RESISTOR METAL FILM 1/5WF 2K OHM R212 1
RES-00-00523 RESISTOR METAL FILM 1/5WF 4.7K OHM R62,108,208 3
RES-00-00545 RESISTOR METAL FILM 1/5WF 5.6K OHM R150 1
RES-00-00589 RESISTOR METAL FILM 1/5WF 9.4K OHM R107,207 2
RES-00-00402 RESISTOR METAL FILM 1/5WF 10K OHM R140,141,211,213,240,241 6
RES-00-00399 RESISTOR METAL FILM 1/5WF 10.5K OHM R60 1
RES-00-00467 RESISTOR METAL FILM 1/5WF 22K OHM R101,152,171,201 4
RES-00-00517 RESISTOR METAL FILM 1/5WF 39K OHM R158 1
RES-00-00537 RESISTOR METAL FILM 1/5WF 47K OHM R102,103,105,106,202,203,205,206 8
RES-00-00610 RESISTOR CARBON FILM 1/5WJ 10 OHM R15,180,181,182,190,191,192 7
RES-00-00716 RESISTOR CARBON FILM 1/5WJ 47 OHM R43,44,45,53,54,55,162 7
RES-00-00606 RESISTOR CARBON FILM 1/5WJ 100 OHM R209 1
RES-00-00615 RESISTOR CARBON FILM 1/5WJ 120 OHM R172 1
RES-00-00622 RESISTOR CARBON FILM 1/5WJ 150 OHM R222 1
RES-00-00723 RESISTOR CARBON FILM 1/5WJ 510 OHM R217 1
RES-00-00728 RESISTOR CARBON FILM 1/5WJ 560 OHM R166,167,168 3
RES-00-00741 RESISTOR CARBON FILM 1/5WJ 680 OHM R156 1
RES-00-00756 RESISTOR CARBON FILM 1/5WJ 820 OHM R173 1
RES-00-00761 RESISTOR CARBON FILM 1/5WJ 910 OHM R16 1
RES-00-00633 RESISTOR CARBON FILM 1/5WJ 1K OHM R31,42,52,92,142,143,153,242,243 9
RES-00-00598 RESISTOR CARBON FILM 1/5WJ 1.5K OHM R161,163,186,227 4
RES-00-00602 RESISTOR CARBON FILM 1/5WJ 1.8K OHM R229 1
RES-00-00676 RESISTOR CARBON FILM 1/5WJ 3.9K OHM R12 1
RES-00-00702 RESISTOR CARBON FILM 1/5WJ 4.7K OHM R01,02,11 3
RES-00-00720 RESISTOR CARBON FILM 1/5WJ 5.6K OHM R225,226 2
RES-00-00751 RESISTOR CARBON FILM 1/5WJ 8.2K OHM R05 1
RES-00-00608 RESISTOR CARBON FILM 1/5WJ 10K OHM R13,14,61,81,151,218,219,224 8
RES-00-00623 RESISTOR CARBON FILM 1/5WJ 15K OHM R34,35,187,216,220,250 6
RES-00-00658 RESISTOR CARBON FILM 1/5WJ 22K OHM R32,91,160 3
RES-00-00663 RESISTOR CARBON FILM 1/5WJ 24K OHM R21,22 2
RES-00-00680 RESISTOR CARBON FILM 1/5WJ 30K OHM R215 1
RES-00-00687 RESISTOR CARBON FILM 1/5WJ 33K OHM R33 1
RES-00-00714 RESISTOR CARBON FILM 1/5WJ 47K OHM R90 1
RES-00-00730 RESISTOR CARBON FILM 1/5WJ 56K OHM R04,199 2
RES-00-00742 RESISTOR CARBON FILM 1/5WJ 68K OHM R25 1
RES-00-00604 RESISTOR CARBON FILM 1/5WJ 100K OHM R144,149,169,228,244 5
RES-00-00620 RESISTOR CARBON FILM 1/5WJ 150K OHM R221 1
RES-00-00647 RESISTOR CARBON FILM 1/5WJ 200K OHM R230 1
RES-00-00654 RESISTOR CARBON FILM 1/5WJ 220K OHM R80 1
RES-00-00706 RESISTOR CARBON FILM 1/5WJ 430K OHM R63 1
RES-00-00053 RESISTOR METAL FILM 1/2WJ 4.7 OHM R196,197 2
RES-00-00018 RESISTOR METAL FILM 1/2WJ 10 OHM R03,165,175 3
RES-00-00016 RESISTOR METAL FILM 1/2WJ 100 OHM R164,174 2
RES-00-00038 RESISTOR METAL FILM 1/2WJ 220 OHM R41,51 2
Electrical Parts List
15
Reference 310a/311a
