ELC-00-00218CAPACITOR ELECTROLYTIC "SMS" 1/50V C163,220 2
ELC-00-00223CAPACITOR ELECTROLYTIC "SMS" 2.2/50V C150,151 2
ELC-00-00229CAPACITOR ELECTROLYTIC "SMS" 4.7/50V C143,219,243 3
ELC-00-00195CAPACITOR ELECTROLYTIC "SMS" 10/16V C06 1
ELC-00-00203CAPACITOR ELECTROLYTIC "SMS" 10/25V C15 1
ELC-00-00220CAPACITOR ELECTROLYTIC "SMS" 10/50V C83 1
ELC-00-00197CAPACITOR ELECTROLYTIC "SMS" 22/16V C102,103,202,203 4
ELC-00-00198CAPACITOR ELECTROLYTIC "SMS" 47/16V C14,210,212,223 4
ELC-00-00205CAPACITOR ELECTROLYTIC "SMS" 47/25V C16 1
ELC-00-00227CAPACITOR ELECTROLYTIC "SMS" 47/50V C57,67 2
ELC-00-00199CAPACITOR ELECTROLYTIC "SMS" 100/16V C11,12,13,159,199 5
ELC-00-00201CAPACITOR ELECTROLYTIC "SMS" 330/16V C911,913,921,923 4
MYC-00-00020CAPACITOR MYLAR 5% 100V 102(M) J C21 1
MYC-00-00031CAPACITOR MYLAR 5% 100V 222(M) J C08 1
MYC-00-00044CAPACITOR MYLAR 5% 100V 683(M) J C226 1
MYC-00-00045CAPACITOR MYLAR 5% 100V 823(M) J C225 1
MYC-00-00094CAPACITOR MYLAR 5% 100V 104(M) J C35,197 2
MYC-00-00156CAPACITOR MYLAR 5% 63V "TL" 184(M) J C228 1
MYC-00-00066CAPACITOR MYLAR 5% 63V "TL" 474(M) J C227 1
MYC-00-00085CAPACITOR MYLAR 5% 63V "TL" 105(M) J C31,32,36 3
CEC-00-00077CAPACITOR CERAMIC DISK 50V "NPO" 10P F C104,204 2
CEC-00-00090CAPACITOR CERAMIC DISK 50V "NPO" 22P F C82,105,106,141,205,206,241 7
CEC-00-00103CAPACITOR CERAMIC DISK 50V "NPO" 47P F C158 1
CEC-00-00108CAPACITOR CERAMIC DISK 50V "NPO" 68P F C152 1
CEC-00-00073CAPACITOR CERAMIC DISK 50V "NPO" 100P F C160,187 2
CEC-00-00086CAPACITOR CERAMIC DISK 50V 220P F C180,181,182 3
CEC-00-00092CAPACITOR CERAMIC DISK 50V 270P F C165,175 2
CEC-00-00101CAPACITOR CERAMIC DISK 50V 470P F C108 1
CEC-00-00074CAPACITOR CERAMIC DISK 50V 102P F C37,101,153,201,211 5
CEC-00-00102CAPACITOR CERAMIC DISK 50V 473P F C33,53,63,154,156,801 6
CEC-00-00076CAPACITOR CERAMIC DISK 50V 104P F C03,22,60,912,922 5
JUP-00-00051 JUMPER 0OHM JUMPER 5m/m J86 1
JUP-00-00043 JUMPER 0OHM JUMPER 6m/m J26,29,30,31,32,76,85,87,91,92 25
J93,100,102,109,110,111,112,113,120,300
J301,302,303,304,305
JUP-00-00044 JUMPER 0OHM JUMPER 7.5m/m J01,02,03,04,05,06,07,08,306,307 12
J308,330
JUP-00-00045 JUMPER 0OHM JUMPER 10m/m J09,10,11,12,13,56,57,58,59,60 16
J82,83,84,88,90,252
JUP-00-00046 JUMPER 0OHM JUMPER 12.5m/m J34,35,36,37,38,250 6
JUP-00-00047 JUMPER 0OHM JUMPER 15m/m J27,28,66,68,69,70,71,79,94 9
JUP-00-00048 JUMPER 0OHM JUMPER 17.5m/m J14,15,16,17,18,19,20,21,22,23 15
J24,25,106,107,108
JUP-00-00074 JUMPER 0OHM JUMPER 19m/m J50,51,52 3
JUP-00-00049 JUMPER 0OHM JUMPER 20m/m J39,40,41,55,61,65,72,73,74,77 12
J89,103
JUP-00-00075 JUMPER 0OHM JUMPER 22m/m J95,96,97,101,104,105 6
JUP-00-00042 JUMPER 0OHM JUMPER 25m/m J33,42,43,44,45,46,47,48,49,53 14
J54,75,78,251
ICO-00-00022 I.C PWM I.C TL494CN U01 1
ICO-00-00170 I.C ELECTRIC VOLUME I.C NJM13600D U105 1
ICO-00-00112 I.C DUAL OP AMP (SIP-08P) NJM2068LD U101,102,103,104,106 5
FET-00-00023 F.E.T N-CHMOSFET FQP50N06 Q43,44,45,53,54,55 6
TRS-00-00188 TRANSISTOR AUDIO POWER NPN TIP35C Q180,181,182 3
TRS-00-00207 TRANSISTOR AUDIO POWER PNP TIP36C Q190,191,192 3
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR Q172 1
Electrical Parts List cont'd
16
Reference 310a/311a
