Infinity 310a - Page 18

DIO-00-00152 DIODE FAST RECOVERY YG225D2 D41,42 2
DIO-00-00048 DIODE RECTIFIER 1N5404 D01 1
DIO-00-00206 DIODE ZENER 1W 15V 1N4744A D911,921 2
RES-00-01223 RESISTOR
MOR/S 2WJ
100 OHM R30 1
RES-00-01270 RESISTOR
MOR/S 2WJ
220 OHM R911,921 2
RES-00-01041 RESISTOR
MOR/S 2WJ
680 OHM R198 1
RES-00-00895 RESISTOR
WIRE WOUND 3WJ
0.1 OHM R183,184,185,193,194,195 6
ELC-00-00235CAPACITOR ELECTROLYTIC "SMS" 100/63V C155,157 2
ELC-00-00276CAPACITOR ELECTROLYTIC "SMS" 470/63V C51,61 2
ELC-00-00727CAPACITOR ELECTROLYTIC "WL" 2200/25V C04,05 2
ELC-00-00618CAPACITOR ELECTROLYTIC "HC/DL" 3300/63V C52,62 2
THS-00-00013THERMISTOR 50K NTC RESISTOR FTD5-350 TH01 1
VOL-00-00352VOLUME
V12L5(9x5)G(PH2D)N15S
3B500B x 2 VR103 1
VOL-00-00335VOLUME
V12L5(9x5)G(PH2D)N15S
3B20KB x 2 VR101 1
VOL-00-00336VOLUME
V12L5(9x5)G(PH2D)N15S
15C50KC x 2 VR102 1
VOL-00-00353VOLUME
V12L5(9x5)G(4R)(PH2D)N15S
A2K x 2 +A200K x 2 VR104 1
COR-TF-00403CORE
5T(0.7x9):17T(0.7x4):10T(0.7x1):10T(0.7x1)
37PHI ISU T01 1
COI-00-00034 INDUCTOR DRUM COIL CL-500 L01,02 2
COI-00-00023 INDUCTOR BAR COIL CL-300 L03 1
COI-00-00019 INDUCTOR AIR COIL CL-200C L196 1
JAC-00-00043RCA JACK DJB-554A RCA101 1
CON-00-00002 WAFER LWL0640-2P CLIP 1
CON-00-00033 WAFER LWL0640-3P 1ST POWER,2ND POWER 2
JAC-00-00050MODULAR 623PCB4-B MOD01 1
TER-00-00030 TERMINAL GOLD PLATED TM0006-01(3P) TER01 1
TER-00-00034 TERMINAL GOLD PLATED TM0009-01(4P) TER02 1
JUP-00-00005 JUMPER METAL JUMPER 55m/m BJ01 1
JUP-00-00002 JUMPER METAL JUMPER 25m/m BJ02 1
WIR-00-00015 WIRE
AWG #22 BLACK 3.2PHI RING RUG
60m/m W02,03 2
WIR-00-00017 WIRE
AWG #22 BLACK 3.2PHI RING RUG
100m/m W04 1
HOD-00-00009FUSE HOLDER WF-9402 FH01 1
TUB-00-00008TEFLON TUBE 0.7PHI 10m/m Q172, TH01 3
FUS-AT-00006AUTO FUSE 30A SET1+ASS'Y1 2
ICO-00-00095
I.C COMPARATOR DIP-8P KIA393P U90 1
RES-00-00437
RESISTOR METAL FILM 1/5WF 1K OHM R97
RES-00-00402
RESISTOR METAL FILM 1/5WF 10K OHM R95
RES-00-00550
RESISTOR METAL FILM 1/5WF 51K OHM R96
RES-00-00556
RESISTOR METAL FILM 1/5WF 56K OHM R94
RES-00-00573
RESISTOR METAL FILM 1/5WF 68K OHM R93
RES-00-00635
RESISTOR CARBON FILM 1/5WJ 1M OHM R98
RES-00-00029
RESISTOR METAL FILM 1/2WJ 1K OHM R192,292
CEC-00-00005
CAPACITOR CERAMIC TUBULAR 50V 103P C91,92,93
CEC-00-00006
CAPACITOR CERAMIC TUBULAR 50V 104P C90
DIO-00-00321
LED BLUE 3PHI MS-L330CBHSK LED1,2,3 3
CON-00-00139
WAFER LAL0640-2P CLIP 1
Electrical Parts List cont'd
17
Reference 310a/311a
