Infinity 610a - Electrical Parts List

IC0-00-00098 IC SHUNT REGULATOR KIA431/KIA431A U505 1 1
DIO-00-00108 DIODE FAST RECOVERY FR154 D71,72,73,81,82,83 6
DIO-00-00003 DIODE RECTIFIER 1N4004 D1,260 2
DIO-00-00041 DIODE ZENER 0.5W,12V 1N5242 D201,202,301,302,401 5
DIO-00-00006 DIODE SWITCHING SIGNAL 1SS133 / 1N4148 D169,402,403,404,405,406,407,408,421,422 15
D501,502,503,504,505
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP "TO-92L" KTA1023Y Q204,206,208,210,304,306,308,310,402,403 11
Q503
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN "TO-92L" KTC1027Y Q203,205,207,209,270,271,303,305,307,309 12
Q401,502
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP "TO-92" KTA1266GR Q262 1
TRS-00-00110 TRANSISTOR SMALL SIGNAL NPN "TO-92" KTC3198GR Q101,260,261,263,501 5
RES-00-00401 RESISTOR METAL FILM 1/5WF 100 OHM R204,304 2
RES-00-00463 RESISTOR METAL FILM 1/5WF 220 OHM R203,303 2
RES-00-00474 RESISTOR METAL FILM 1/5WF 240 OHM R405 1
RES-00-00586 RESISTOR METAL FILM 1/5WF 820 OHM R116 1
RES-00-00590 RESISTOR METAL FILM 1/5WF 910 OHM R202,206,302,306 4
RES-00-00437 RESISTOR METAL FILM 1/5WF 1K OHM R151,156 2
RES-00-00393 RESISTOR METAL FILM 1/5WF 1.5K OHM R558 1
RES-00-00482 RESISTOR METAL FILM 1/5WF 2K OHM R117 1
RES-00-00523 RESISTOR METAL FILM 1/5WF 4.7K OHM R113,505,506 3
RES-00-00581 RESISTOR METAL FILM 1/5WF 8.2K OHM R404 1
RES-00-00589 RESISTOR METAL FILM 1/5WF 9.4K OHM R111,112 2
RES-00-00402 RESISTOR METAL FILM 1/5WF 10K OHM R150,155 2
RES-00-00409 RESISTOR METAL FILM 1/5WF 11K OHM R118 1
RES-00-00459 RESISTOR METAL FILM 1/5WF 21K OHM R152,157 2
RES-00-00467 RESISTOR METAL FILM 1/5WF 22K OHM R107,108,109,110 4
RES-00-00537 RESISTOR METAL FILM 1/5WF 47K OHM R103,104,105,106,402,403,503,504 8
RES-00-00636 RESISTOR CARBON FILM 1/5WJ 1 OHM R207,208,211,212,307,308,311,312 8
RES-00-00610 RESISTOR CARBON FILM 1/5WJ 10 OHM R508 1
RES-00-00660 RESISTOR CARBON FILM 1/5WJ 22 OHM R528 1
RES-00-00716 RESISTOR CARBON FILM 1/5WJ 47 OHM R51,52,53,61,62,63 6
RES-00-00606 RESISTOR CARBON FILM 1/5WJ 100 OHM R115,555 2
RES-00-00622 RESISTOR CARBON FILM 1/5WJ 150 OHM R125 1
RES-00-00685 RESISTOR CARBON FILM 1/5WJ 330 OHM R420,421,422,423 4
RES-00-00712 RESISTOR CARBON FILM 1/5WJ 470 OHM R241,264,341 3
RES-00-00723 RESISTOR CARBON FILM 1/5WJ 510 OHM R120,122 2
RES-00-00633 RESISTOR CARBON FILM 1/5WJ 1K OHM R50,60,153,158,509,521,529,553,554 9
RES-00-00598 RESISTOR CARBON FILM 1/5WJ 1.5K OHM R133,511 2
RES-00-00602 RESISTOR CARBON FILM 1/5WJ 1.8K OHM R135 1
RES-00-00637 RESISTOR CARBON FILM 1/5WJ 2.2K OHM R201,205,301,305,517 5
RES-00-00672 RESISTOR CARBON FILM 1/5WJ 3.3K OHM R522 1
RES-00-00702 RESISTOR CARBON FILM 1/5WJ 4.7K OHM R114,262,414,515,516,552 6
RES-00-00720 RESISTOR CARBON FILM 1/5WJ 5.6K OHM R131,132,272 3
RES-00-00608 RESISTOR CARBON FILM 1/5WJ 10K OHM R44,119,123,128,129,130,261,263,406,407 22
R409,410,412,416,418,419,507,525,526,551
R556,559
RES-00-00623 RESISTOR CARBON FILM 1/5WJ 15K OHM R121,126 2
RES-00-00630 RESISTOR CARBON FILM 1/5WJ 18K OHM R415 1
RES-00-00658 RESISTOR CARBON FILM 1/5WJ 22K OHM R101,102,523 3
RES-00-00666 RESISTOR CARBON FILM 1/5WJ 27K OHM R417 1
RES-00-00680 RESISTOR CARBON FILM 1/5WJ 30K OHM R124 1
RES-00-00714 RESISTOR CARBON FILM 1/5WJ 47K OHM R512,513 2
RES-00-00748 RESISTOR CARBON FILM 1/5WJ 75K OHM R514 1
RES-00-00604 RESISTOR CARBON FILM 1/5WJ 100K OHM R134,138,154,159,169,230,231,232,236,237 17
R273,330,331,332,336,337,510
RES-00-00620 RESISTOR CARBON FILM 1/5WJ 150K OHM R127,270,271 3
RES-00-00654 RESISTOR CARBON FILM 1/5WJ 220K OHM R413 1
RES-00-00755 RESISTOR CARBON FILM 1/5WJ 820K OHM R260 1
RES-00-00635 RESISTOR CARBON FILM 1/5WJ 1M OHM R411,520,524,527 4
RES-00-00639 RESISTOR CARBON FILM 1/5WJ 2.2M OHM R408 1
Electrical Parts List
Power Amplifier Reference 610a/611a
16
