FIGURE 3 LINEAR BOARD UPGRADE (cont’d)
Model
Identification
120V
STATUS
ACTION
IL50
No Label
Needs Reliability
Upgrade
Follow Steps Outlined Above
IL50
Small White
Rectangular label
On Amp faceplate
“Rev II 2002-XXX”
Modified by factory NONE REQUIRED
8
9
10
A & B
11
23
IL50
