IL50 L/R
3
Specifications
IL50 L/R Frequency Response: 32Hz - 22,000Hz (±3dB)
Recommended Amplifier Power Range 15-150 watts*
Subwoofer Amplifier Output: 250 watts (In to 8Ω from 20 Hz - 100Hz
with no more than 0.1% THD)
Sensitivity: 88dB (2.83V @ 1 meter)
Nominal Impedance: 8Ω
Crossover Frequencies: 150Hz; 2500Hz, 24dB/octave,
Low-Frequency Driver: 10" C.M.M.D., magnetically shielded
Mid-Bass Driver: 6-1/2” C.M.M.D., magnetically shielded
High-Frequency Driver: 1” C.M.M.D., magnetically shielded
Dimensions (H x W x D): 42" x 8-3/4" x 14-1/2"
(1067mm x 222mm x 368mm)
Weight: 60 lb (27kg)
* The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.
