Infinity INTERMEZZO 1.2s - Page 23

RC0039 R165,R170,R173 3 RES, CF 2K2 1/4W 5%
RC0083 R149,R150,R158 3 RES, CF 100K 1/4W 5%
RC0111 R143,R148 2 RES, CF 680R 1/4W 5%
RC0115 R167 1 RES, CF 47K 1/4W 5%
RC0135 R168 1 RES, CF 150K 1/4W 5%
RC0273 R126,R130,R135,R141,R146 5 RES, ZERO OHM 1/4W
RC0277 R171 1 RES, CF 5M6 1/4W 5%
RC0281 R166 1 RES, CF 510K 1/4W 5%
RM0001 R151,R152 2 RES, MF 1K00 1/4W 1%
RM0002 R110,R111,R112 3 RES, MF 10K0 1/4W 1%
RM0011 R104, R105, R106, R107, R116 5 RES, MF 100K 1/4W 1%
RM0019 R115 1 RES, MF 1K30 1/4W 1%
RM0075 R137 1 RES, MF 475R 1/4W 1%
RM0091 R108,R109 2 RES, MF 3K65 1/4W 1%
RM0106 R113 1 RES, MF 14K0 1/4W 1%
RM0113 R118,R119,R120 3 RES, MF 20K0 1/4W 1%
RM0115 R114 1 RES, MF 23K7 1/4W 1%
RM0142 R139,R144 2 RES, MF 287K 1/4W 1%
RM0195 R133 1 RES, MF 187K 1/4W 1%
RM0110 R122,R124,R127,R128 4 RES, MF 17K4 1/4W 1%
RM0269 R136 1 RES, MF 93K1 1/4W 1%
RM0290 R142,R147 2 RES, MF 143K 1/4W 1
RM0351 R117 1 RES, MF 9K53 1/4W 1%
RP0105 R123 1 POT, B50K QUAD KNURL SHAFT
RM0403 R101, R103 2 RES, MF 54K9 1/4W 1%
RC0192 R100, R102 2 RES, CF 2K0 1/2W 5%
dni R121, R125, R129, R131, 8 (Do Not Insert)
R134, R138, R140, R145
Miscellaneous
JC0052 J101 1 CNCTR, RCA QUAD JACK
JC0064 J105 1 DC POWER JACK 2MM DIA
JC0176 J100 1 8X BINDING POSTS GOLD KNURL
JH0008 J102 1 CNCTR, HEADER 5PIN .100CTR
JH0074 J103,J104 2 CNCTR, HEADER 8PIN LOCKING .1C
SR0006 2 SWITCH, CAP FOR SR0005 USED ON S101 &
S102
SR0017 S101,S102 2 SWITCH, 2 POLE 2PDT
SR0041 S100 1 DPST PUSH SWITCH TV-8
SR0042 1 SWITCH CAP, 8.8X10.5MM CYL BLK
PCB, RABOS
Semiconductors
UA0009 U200 1 OPAMP, QUAD 14P DIL TL074/084
UA0010 U201 1 OPAMP, DUAL 8PIN DIL TL082
QB0017 Q204 1 TRANS, NPN 150V 0.6A 2N5551TR
QM0035-S Q201,Q202,Q205 3 JFET, J111 SELECTED TR ONLY
QB0017 Q200 1 TRANS, NPN 150V 0.6A 2N5551
Electrical Parts List (Cont.)
Part# Reference Designator Qty Description
23
INTERMEZZO 1.2s
