Electrical Parts List (Cont.)
Part# Reference Designator Qty Description
Resistors
RC0148 R210 1 RES, CF 10M 1/4W 5%
RM0001 R207,R208 2 RES, MF 1K00 1/4W 1%
RM0002 R200,R201,R214,R216,R220, 10 RES, MF 10K0 1/4W 1%
R225,R228, R229,R230, R233
RM0003 R219, R224 2 RES, MF 15K0 1/4W 1%
RM0012 R215 1 RES, MF 100R 1/4W 1%
RM0024 R203 1 RES, MF 2K21 1/4W 1%
RM0031 R231 1 RES, MF 3K32 1/4W 1%
RM0076 R204 1 RES, MF 562R 1/4W 1%
RM0078 R209 1 RES, MF 680R 1/4W 1%
RM0080 R217,R223 2 RES, MF 825R 1/4W 1%
RM0091 R211 1 RES, MF 3K65 1/4W 1%
RM0260 R232 1 RES, MF 1M0 1/4W 1%
RM0271 R206 1 RES, MF 110K 1/4W 1%
RM0281 R222,R227 2 RES, MF 6K04 1/4W 1
RM0315 R212 1 RES, MF 2K67 1/4W 1%
RM0369 R221,R226 2 RES, MF 340R 1/4W 1%
RM0370 R202 1 RES, MF 9K31 1/4W 1%
RM0402 R234 1 RES, MF 11K5 1/4W 1%
RP0087 R205,R213 2 POT, A10K DUAL 12MM HOR SEL
RP0088 R218 1 POT, C10K DUAL 12MM HOR SEL
Capacitors
CE0003 C203,C204 2 CAP, E 2.2UF 50V 20% 105C
CF0045 C200,C201,C202 3 CAP, F .1UF 63DC 5% 5MMLS
CE0003 C210,C211 2 CAP, E 2.2UF 50V 20% 105C
CF0045 C204,C205,C206,C207,C208 5 CAP, F .1UF 63DC 5% 5MMLS
Miscellanous
JH0074 J200 1 CNCTR, HEADER 8PIN LOCKING .1C
PCB, Volume Board
RC0273 R237 1 RES, ZERO OHM 1/4W
RP0097 R235 1 POT, A10K SINGLE/BRKT D SHAFT
RX0096 R236 1 RES, MO 2K2 1W 5%
RP0106 1 POT, KNOB INT 1.2 LEVEL
HS0047 4 SCREW, #6-32X3/4 PAN PHIL BLK TO MOUNT
VOLUME BOARD TO RABOS BOARD
MM0070 1 MISC, GASKET Used on RABOS Housing
MZ0034 4 STANDOFF, 3/8 SPACER NYLON
MZ0036 1 STANDOFF, 14MM LED 2PIN
RABOS CUP 1.2 1 INTERMEZZO 1.2 RABOS HOUSING
C0186 1 CNCTR, FEM-FEM HARN 8P 18 SHIELD
MM0075 1 MISC, RUBBER GROMMET RABOS HSG FOR
SEALING RABOS HOUSING
DL0014 D200 1 LED, 3MM BICOLOR RED/GR
