Electrical Parts List (Cont.)
Part# Reference Designator Qty Description
Miscellaneous
480033 3 SUB, #18R 4 1/4 187X032/187X032 1PC. IEC
LIVE TO FUSE HOLDER; 1PC. FUSE
HOLDER TO SWITCH; IPC. IEC NEUTRAL TO
SWITCH
480104 1 SUB, #16X2 24 205X032/250X032 SPEAKER
WIRE
930052 1 CUP ENCLOSURE
930053 1 U-BRACKET
FH0006 1 FUSE, HOLDER PANEL MT
FS0027 1 FUSE, 6A 250V 1.25X.25 GLASS
HS0047 12 SCREW, #6-32 3/4 PAN PHIL BLK 4PCS.
USED TO MOUNT LINEAR BOARD; 4 PCS
USED TO MOUNT POOWER SUPPLY; 4 PCS
USED TO SCREW VOLUME BOARD ONTO
RABOS BOARD
HS0057 3 SCREW, #8-32X1/2 PAN PHIL BLK USED TO
ATTACH U-BRACKET TO ENCLOSURE
HS0060 14 SCREW, #6-32 X 3/8 PP BLACK 4PCS USED
TO MOUNT EMI PCB IN HOUSING; 4 PCS
USED TO MOUNT EMI HOUSING U-
BRACKET; 6 PCS TO SECURE PANEL TO
ENCLOSURE
HS0078 2 SCREW, #4 HI-LOW PAN PHIL BLK USED TO
SECURE RABOS BOARD IN HOUSING
INTERMEZZO 1.2H 1 INTERMEZZO 1.2 MAIN ENCLOSURE
INTERMEZZO 1.2P 1 INTERMEZZO 1.2 MAIN PANEL
JC0079 1 CNCTR, 5PIN FEM-FEM HARNESS 7 J401
ON POWER SUPPLY TO J302 ON LINEAR
JC0129 1 CNCTR, AC IEC SOCKET .250 2PIN
JC0179 1 CNCTR, 5-PIN FEM-FEM HARNESS
SHIELDED 14 J502 ON EMI TO J102 ON
FEATURE
JC0180 1 CNCTR, 8-PIN FEM-FEM HARNESS
SHIELDED 18 J104 ON FEATURE TO J200
ON RABOS
JC0181 1 CNCTR, 8-PIN FEM-FEM HARNESS
SHIELDED 18 J103 ON FEATURE TO J301
ON LINEAR
JC0182 1 2-CONDUCTOR AC LAMP CORD 8
4X187X032
MZ0042 4 STANDOFF, 3/8 #6-32 NYLON HEX USED TO
MOUNT LINEAR BOARD
SR0032 1 SWITCH, ROCKER TV5
HS0054 7 SCREW, #4-1/2 TYPE AB PP BLK 6 PCS.
USED TO SECURE BINDING POSTS TO
PANEL; 1 PC. USED TO SECURE RCA
JACKS TO PANEL
HS0088 1 SCREW, #8-32X1.3/4 PAN PHIL BL USED TO
MOUNT U BRACKET TO ENCLOSURE
