INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
CE0106 C305, C315, C326 3 CAP, E 22UF 35V BP 8X11 5MMLS
CF0008 C342 1 CAP, F 2200PF 100V 5% 5MMLS
CF0035 C306, C316 2 CAP, F .022UF 100V 5% 5MMLS
CF0045 C302, C303 2 CAP, F .1UF 63DC 5% 5MMLS
CC0020 C335, C366 2 CAP, CA 470PF 100V 5%
CC0040 C313, C324, C331 3 CAP, CA 4700PF 100V 10%
CC0059 C304, C311, C312, C322, C323 5 CAP, CA .1UF 100V 20%
CC0065 C337, C367 2 CAP, CA 2200P 100V 10%
CC0072 C341 1 CAP, CA 100PF 100V NPO 10%
CC0082 C350, C351, C370, C371 4 CAP, CA .1UF 50V 20%
CC0087 C332, C338 2 CAP, CA .01UF 100V 20%
CC0108 C307, C317 2 CAP, CA 22PF 50V 10%
CC0017 C340 1 CAP, C 330PF 100V 10% 5MMLS BU
CC0078 C344 1 CAP, C .22UF 50V 10% .2LS BULK
CC0079 C343 1 CAP, C .1UF 50V 20% .2LS TR
CE0121 C355, C356 2 CAP, E 470UF 200V 20% 30X25
CF0146 C361 1 CAP, F 6.8UF 250V 10% 27MMLS
Miscellaneous
540130 L302 1 IND, CM CHOKE 150UH ELYTONE
BF0007 L301 1 BEAD, FERRITE
JH0008 J302 1 CNCTR, HEADER 5PIN .100CTR
JH0016 J303 1 CNCTR, HEADER 2PIN .100CTR
JH0074 J301 1 CNCTR, HEADER 8PIN LOCKING .1C
KS0017 TH302, TH303 2 THERMISTOR, 100K @ 25C NTC BUL
KS0019 TH301 1 THERMISTOR, PTH9L04BD22TS2F510
MT0003 FO304 1 TERM, FASTON MALE PCMT 250X032
MT0005 2 TERM, KWIKDISC .187 X.032 FEMA
USED ON END OF 480022 AND 48028
MT0023 FO301, FO302, FO308, FO311 4 TERM, FASTON MALE PCMT 187X032
MT0036 FO303 1 TERM, FASTON MALE PCMT 205X032
Power Supply PCB
Semiconductors
DZ0021 Z401, Z402, Z403, Z404, Z405, Z406, Z407, Z408 8 ZENER, 500MW 15V 5% 1N5245B
QB0018 Q401 1 TRANS, PNP 150V 0.6A 2N5401TR
DS0002 D409, D410 2 RECT, 100MA 200V SIGNAL 1N3070
DR0084 D407, D408 2 RECT, 8A 600V ULTRAF MUR1660CT
DR0086 D403, D404, D406 3 RECT, 1A 600V ULTRAFAST MUR160
DD0003 Q402 1 RECT, 1A2 60V DIAC
QM0055 Q403, Q404, Q406, Q407 4 MOSFET, IRF740 TO220AB IR ONLY
Resistors
RX0050 R439, R440 2 RES, MO 10 ohms1W6 5%
RC0138 R422 1 RES, CF 200K 1/4W 5%
RM0001 R401 1 RES, MF 1K00 1/4W 1%
RM0012 R405 1 RES, MF 100 ohms1/4W 1%
RM0075 R406, R408, R409, R411, R413, R415, R416, R418, 8 RES, MF 475 ohms1/4W 1%
RM0198 R402 1 RES, MF 205K 1/4W 1%
RM0340 R407, R410, R414, R417, R419, R420, R425, R426 8 RES, MF 22 ohms0.6W 1% FLAMEPROOF
RX0046 R403, R421 2 RES, MO 47K 1W 5%
