INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
Capacitors
CC0124 C446, C447 2 CAP, C .01UF 500V DISC .2LS TR
CE0013 C415, C416, C418 3 CAP, E 47UF 50V 20% 5MMLS
CF0093 C406, C408, C412, C414 4 CAP, F 4700PF 100V 5% 5MMLS
CC0087 C409, C421 2 CAP, CA .01UF 100V 20%
CC0130 C432, C448 2 CAP, CY1 4700PF 250V 20% .4LS
CE0040 C401, C402, C403, C422, C423, C424 6 CAP, E 680UF 200V 25X35 85DEG
CF0050 C426, C427, C449, C450 4 CAP, F .1UF 250V 10% 10MMLS
CF0127 C430, C431 2 CAP, F .22UF 250V 10% 5MMLS
Miscellaneous
500109 2 XFMR, POWER 500W ETD44 CLASS F
T403, T404 CUT AWAY PIN #18 FOR
BOTH LOCATIONS
JH0008 J401 1 CNCTR, HEADER 5PIN .100CTR
KS0021 TH401 1 SURGISTOR, 4R 8A 70J SL154R008
MT0023 FO401, FO402, FO403, FO404 4 TERM, FASTON MALE PCMT 187X032
AC Filter PCB
DR0038 D502, D503, D504, D505 4 RECT, 1A 400V GENERAL 1N4002
DS0001 D512 1 RECT, 100mA 75V SIGNAL 1N4148T
DZ0012 Z502, Z503 2 ZENER, 500MW 3.9V 5% 1N5228B
DB0006 D501 1 RECT, 8A 400V BRIDGE
QB0002 Q501 1 TRANS, NPN 40V .6A TO92 2N4401
UV0007 U502 1 VREG, LINEAR TO220 LM7905CT
UV0013 U501 1 VREG, +5V 100MA TO220 LM7805CT
RC0004 R501 1 RES, CF 1M0 1/4W 5%
CE0003 C505, C506 2 CAP, E 2.2UF 50V 20% 105C
CE0103 C503, C504 2 CAP, E 100UF 35V 85DEG 5MMLS
CC0059 C507 1 CAP, CA .1UF 100V 20%
CF0057 C501, C502 2 CAP, FX .22UF 250V 10%
JH0008 J502 1 CNCTR, HEADER 5PIN .100CTR
KV0001 Z501 1 VARISTOR, 275V 100J .6W
MT0023 FO503, FO504 2 TERM, FASTON MALE PCMT 187X032
RX0083 R503 1 RES, MO 150R 3W 5%
SR0038 SW502 1 SWITCH, SPST TV5 5A 12V
500103 T501 1 XFMR, POWER 60HZ 24V FT3245
540124 L501 1 IND, CM CHOKE YT7271
HPF Switch Board
JH0093 J105 1 CNCTR, HEADER 4PIN .156CTR LCK
SR0044 S101 1 SWITCH, PUSH DPDT 125VAC 7A
Rabos PCB (Left)
Semiconductors
UA0009 U1 1 OPAMP, QUAD 14P DIL TL074/084
UA0010 U2 1 OPAMP, DUAL 8PIN DIL TL082
QM0035-S Q1, Q2 2 JFET, J111 SELECTED TR ONLY
QB0017 Q3 1 TRANS, NPN 150V 0.6A 2N5551TR
Resistors
RP0087 R17, R20 2 POT, A10K DUAL 12MM HO ohms5%
