INTERMEZZO 4.1t

Electrical Parts List (cont.)

Part# Reference Designator Qty. Description

RP0088 R6 1 POT, C10K DUAL -10% MID 1.5K

RC0148 R30 1 RES, CF 10M 1/4W 5%

RM0001 R27, R29 2 RES, MF 1K00 1/4W 1%

RM0002 R1, R2, R4, R10, R15, R16, R24, R26, R32, R37 10 RES, MF 10K0 1/4W 1%

RM0003 R9, R14 2 RES, MF 15K0 1/4W 1%

RM0012 R3 1 RES, MF 100 ohms1/4W 1%

RM0024 R25 1 RES, MF 2K21 1/4W 1%

RM0031 R36 1 RES, MF 3K32 1/4W 1%

RM0042 R31 1 RES, MF 681 ohms1/4W 1%

RM0080 R5, R11 2 RES, MF 825 ohms1/4W 1%

RM0178 R34 1 RES, MF 10K2 1/4W 1%

RM0260 R28 1 RES, MF 1M0 1/4W 1%

RM0271 R22 1 RES, MF 110K 1/4W 1%

RM0281 R8, R13 2 RES, MF 6K04 1/4W 1%

RM0315 R19 1 RES, MF 2K67 1/4W 1%

RM0369 R7, R12 2 RES, MF 340 ohms1/4W 1%

RM0370 R21 1 RES, MF 9K31 1/4W 1%

RM0377 R18 1 RES, MF 3K57 1/4W 1%

RM0378 R23 1 RES, MF 549 ohms1/4W 1%

Capacitors

CE0115 C4, C5 2 CAP, E 1UF 63V 6X11 85C 5MMLS

CF0045 C1, C2, C3 3 CAP, F .1UF 63DC 5% 5MMLS

Miscellaneous

JH0061 J4 1 CNCTR, HEADER 5PIN

JH0074 J3 1 CNCTR, HEADER 8PIN LOCKING .1C

Rabos PCB (Right)

UA0009 U1 1 OPAMP, QUAD 14P DIL TL074/084

UA0010 U2 1 OPAMP, DUAL 8PIN DIL TL082

QM0035-S Q1, Q2 2 JFET, J111 SELECTED TR ONLY

Resistors

RP0087 R17, R20 2 POT, A10K DUAL 12MM HO ohms5%
