INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
RM0377 R18 1 RES, MF 3K57 1/4W 1%
RM0378 R23 1 RES, MF 549 ohms1/4W 1%
Capacitors
CE0115 C4, C5 2 CAP, E 1UF 63V 6X11 85C 5MMLS
CF0045 C1, C2, C3 3 CAP, F .1UF 63DC 5% 5MMLS
Miscellaneous
JH0061 J4 1 CNCTR, HEADER 5PIN
JH0074 J3 1 CNCTR, HEADER 8PIN LOCKING .1C
Volume PCB (Left)
DL0014 D1 1 LED, 3MM BICOLOR RED/GR
MZ0036 1 STANDOFF, 14MM LED 2PIN (FOR D1)
RC0273 R2 1 RES, ZERO OHM 1/4W
RP0097 R1 1 POT, A10K SINGLE/BRKT D SHAFT
RX0096 R3 1 RES, MO 2K2 1W 5%
Volume PCB (Right)
DL0014 D1 1 LED, 3MM BICOLOR RED/GR
MZ0036 1 STANDOFF, 14MM LED 2PIN (FOR D1)
RC0273 R2 1 RES, ZERO OHM 1/4W
RP0099 R1 1 POT, C10K SINGLE/BRKT D SHAFT
RX0096 R3 1 RES, MO 2K2 1W 5%
Miscellaneous
HS0073 2 SCREW, #6-19X3/8 HL PP ZNC
USED ON THE RABOS RIGHT HOUSING
HS0087 4 SCREW, #6-19X1 HL PP ZNC
USED ON THE RABOS RIGHT HOUSING
JC0186 1 CNCTR, FEM-FEM HARN 8P 18" SHI TO
CONNECT J3 ON RABOS TO J102 ON FEATURE
MM0075 1 MISC, RUBBER GROMMET RABOS HSG
AT OPENING OF PLASTIC HOUSING FOR
RIBBON CABLE.
MZ0034 4 STANDOFF, 3/8" SPACER NYLON
USED ON THE VOLUME BOARD
RP0098 1 POT, KNOB INT 2.6 LEVEL RIGHT
USED ON R1
810056 12 HTSNK, FET CLIP .9X.5X.2 FOR THE FETS
810066 6 HTSNK, FET CLIP HPS SERIES
USED ON D407, D408, Q403, Q404, Q406, Q407
ON THE POWER BOARD
810088 1 HTSNK, BRIDGE 1X2 FOR D501 BRIDGE
810096 1 HTSNK, PRIMARY LF SERIES
USED ON THE POWER BOARD
810099 1 HTSNK, DIODE LF SERIES
USED ON THE POWER BOARD
930056 1 COVER, PWR SUPPLY PLASTIC 4.1
930057 1 BRACKET, INTERMEZZO 4.1M
930058 1 CUP, AMP BUCKET INTERMEZZO 4.1
930059 1 PANEL, INTERMEZZO 4.1M
FH0012 1 FUSE, HOLDER PANEL MT SEALED
