INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
FS0027 1 FUSE, 6A 250V 1.25X.25 GLASS
HN0003 1 NUT, HEX NYLON #6-32 L302
ON THE LINEAR BOARD
HN0006 9 NUT, HEX KEP #6-32 ZNP
1PC FOR BRIDGE HEATSINK; 4PC FOR THE
PRIMARY AND DIODE HEATSINK; 4PC TO ATTACH
METAL HEATSINK STANDOFF TO BOARD
HS0006 1 SCREW, #6-32X3/8 100 PHIL ZNP
FOR BRIDGE HEATSINK
HS0047 4 SCREW, #6-32X3/4 PAN PHIL BLK
TO SCREW VOLUME BOARD TO RABOS BOARD
HS0054 3 SCREW, #4-1/2 TYPE AB PP BLK
1PER FOR THE RCA JACKS; 2PER TO SECURE
HIGH LEVEL INPUTS TO PANEL
HS0060 4 SCREW, #6-32X3/8 PAN PHIL BLK
USED ON THE PRIMARY AND DIODE HEATSINK
ON THE POWER BOARD
HS0062 12 SCREW, #6-1/2 TYPE B PP BLK
ON THE FET CLIPS
HS0065 13 SCREW, #6-32X1/4 PAN PHIL BLK
4PC TO MOUNT LINEAR BOARD; 4PC TO MOUNT
POWER SUPPLY; 4PC TO MOUNT FINGER
PROTECTOR TO U BRACKET; 1PC F0R MM0025
ON FEATURE BOARD
HS0066 4 SCREW, #6-32X1/2 PAN PHIL BLK
TO SECURE FINGER PROTECTOR TO POWER
SUPPLY HEATSINK STANDOFFS
HS0067 2 SCREW, #6-3/8 TYPE A PP BLK
2PC TO SUPPORT 660035
HS0073 4 SCREW, #6-19X3/8 HL PP ZNC
MOUNT EMI BOARD IN PLASTIC BUCKET
HS0079 1 SCREW, #6-32X1.25 FL SLOT NYL
L302 ON THE LINEAR BOARD
HS0092 4 SCREW, #6-19X3/8 HL PP BLK
TO MOUNT U BRACKET TO PLASTIC BUCKET
HS0093 2 SCREW, M3X16MM 100CS PHIL BLK
TO ALIGN SR0044
HS0094 4 SCREW, #6-19X3/8 82UC TYPE B
TO SECURE PANEL TO PLASTIC BUCKET
JC0071 1 CNCTR, FEM-FEM HARNESS 8PIN 9"
TO CONNECT J101 ON FEATURE BD TO J301
ON LINEAR BD
JC0079 1 CNCTR, FEM-FEM HARNESS 5PIN 7"
TO CONNECT J502 ON EMI BD TO J100
JC0094 1 CNCTR, 2PIN GOLD PC MT
HIGH LEVEL INPUT
JC0129 1 CNCTR, AC IEC SOCKET .250 2PIN
ON THE PANEL
JC0134 1 CNCTR, FEM-FEM HARNESS 5PIN 9"
TO CONNECT J401 ON POWER BOARD TO
J302 ON LINEAR BD
JC0180 1 CNCTR, FEM-MAL HARN 8P 18" SHI
TO CONNECT J102 ON FEATURE BD TO J3
ON RABOS
