INTERMEZZO 4.1t
Electrical Parts List (cont.)
Part# Reference Designator Qty. Description
JC0182 1 CNCTR, 2PIN FEM/2XFEM FASTON
TO LIVE AND NEUTRAL FROM SWITCH
TO THE EMI BOARD
JC0192 1 CNCTR, FEM-MAL HARN 2P 20" #16
CONNECT TO FO101(.250) TO FO103(.205)
ON FEATURE BOARD
JC0193 1 CNCTR, FEM-MAL HARN 2P 49"/30"
FEMALE RECEPTACLE TO CONNECT TO
MALE PLUG OF JC0192
JC0194 1 CNCTR, FEM-MAL HARN 4P 21" #18
FEMALE CRIMP TERMINAL HOUSING TO
CONNECT TO J105 ON HPF SWITCH BOARD
JC0195 1 CNCTR, FEM-FEM HARN 4P 48" #18
FEMALE RECEPTACLE TO CONNECT TO MALE
PLUG OF JC0194
MM0080 1 MISC, PANEL GASKET ITM4.1T TO PERIMETER
OF AMP HOUSING
MS0014 1 MISC, CERAMIC PLATE TO-220
D324 ON THE LINEAR BOARD
MS0017 11 MISC, CERAMIC PLATE TO-220
Q305, Q306, Q307, Q310, Q311, Q312, Q319,
Q320, Q321, U302, U303 ON THE LINEAR BOARD
MT0005 6 TERM, KWIKDISC .187 X.032 FEMA
ON EACH END OF 480001 AND 480003; ON ONE
END OF 480022 AND 480028
MZ0024 2 STANDOFF, .5" NYLON
TO SUPPORT 660035 BOARD
MZ0041 4 STANDOFF, #6 1.5" HEX FEM-MALE
TO SECURE PRIMARY AND SEC HEATSINKS.
THE MALE END MUST BE FASTENED TO THE
POWER BOARD.
MZ0043 2 STANDOFF, .12ID .25OD .37L PVC
TO ALIGN SR0044
SR0032 1 SWITCH, ROCKER TV5 POWER
SR0042 1 SWITCH, CAP 8.8X10.5MM CYL BLK
USED ON SR0044
TS0020 2 FIBREGLASS, HT210 #2AWG 6"
TO SLEEVE SEC DC+ AND DC- OUTPUT OF
POWER; BOARD AND DC+ AND DC- INPUT TO
POWER BOARD
HS0073 2 SCREW, #6-19X3/8 HL PP ZNC
USED ON THE RABOS LEFT HOUSING
HS0087 4 SCREW, #6-19X1 HL PP ZNC
USED ON THE RABOS LEFT HOUSING
JC0186 1 CNCTR, FEM-FEM HARN 8P 18" SHI
CONNECT J3 ON RABOS TO J102 ON FEATURE
MM0075 1 MISC, RUBBER GROMMET RABOS HSG
AT OPENING OF PLASTIC HOUSING FOR
RIBBON CABLE
MZ0034 4 STANDOFF, 3/8" SPACER NYLON
USED ON THE VOLUME BOARD
RABOS CUP 2.6L 1 CUP, RABOS INTERMEZZO 2.6 LEFT
RP0100 1 POT, KNOB INT 2.6 LEVEL LEFT
