Infinity Kappa Subwoofer - Connection Method 2

8
◆
Kappa Series Powered Subwoofer – Owner’s Manual
Method 2
Disconnect the jumper or cable that links your preamplifier ouput and power
amplifier input
• Connect the preamp output to the kappa subwoofer line input
• Connect the kappa suwoofer line output to the power amplifier input (MAIN IN)
PREAMP OUTPUTS
L
R
(ONE CHANNEL SHOWN)
L
R
POWER AMPLIFIER INPUTS
Figure 3.
