2. Specification:
3. Panel Layout
About this chapter
The installation chapter gives an overview of the interface of iShare X.
Overview
⚫ Hardware Interface
◼ iShare X400 Front Panel
iShare X400 Specification
HDMI output
1x HDMI 19-pin female connector
Video Output Resolution
3840x2160@60Hz, 3840x2160@30Hz,
1920x1080@60Hz, 1280x720@60Hz
Format Compliance
HDMI1.4/ HDMI2.0
Video Capacity:
1080P @ <60Hz Airplay for iOS devices
1080P @ <60Hz "iShare X2" app
1080P @ <60Hz for all show-me button
HDCP
HDCP1.4/ HDCP2.2
Analog Audio Output
1x 3.5mm PC audio female connectors
LAN port
RJ45 x2: 1,000Mbps x1, 100Mbps x1
USB interface
USB3.0 x3, USB 2.0 x1, Type-C x2
Audio Input
AirPlay, Miracast, DLNA, Windows/MAC, USB/BT
Speakphone
Control connectors
3.5mm Phoenix terminal/ RS232 interface
Number of window simultaneous on
screen
≥4+14 (4 main windows+ 14 thumbnail windows)
Number of simultaneous connections
≥16
Data rate in wireless
Up to 1,200Mbps
Video Playback Frame Rate
20-60 FPS
Latency
＜100ms, Min 20ms
Wireless transmission protocol
WIFI IEEE 802.11 a/g/n/ac
Frequency band
2.4 GHz & 5 GHz
Dimension (W x D x H)
220mm x 120mm x 41mm（including antenna：
220mm x 120mm x 145mm）
Weight
1.0kg
Temperature
-4° ~ +140° F (-20° ~ +60° C)
Humidity (Storage / Operating)
20%-90% (non-condensing)
DC Power
12V / POE
POE standard
IEEE802.3af
Power Consumption
10W (MAX)
