Table 2 Infoblox 800 Series Rear Panel Components
Component Description
Air Vent An air vent that allows warm air to flow out of the appliance. Do not obstruct.
Fan A fan to help maintain optimum operating temperature. Do not obstruct.
UID LED Blue = UID is activated through pressing the UID button on the appliance.
Blinking Blue = UID is activated through the Infoblox Grid Manager or CLI command Dark = UID is deactivated
On/Off Switch A power switch to turn the power supply on and off.
Power Outlet An IEC C-14 chassis plug for connecting the appliance to a standard AC power source.
System, Environmental, and Power Specifications
System specifications describe the physical characteristics of the Infoblox 800 Series appliances. Environmental specifications describe Infoblox
800 Series temperature and moisture limits. Power specifications describe the electrical range within which the appliance circuitry can operate.
System Specifications
Form : 1-U rack-mountable applianceFactor
Dimensions: (44mm H X 441 W X 437 D)
Weight: Approximately 25 pounds (11.33 kg)
Ethernet : MGMT, HA, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-TPorts
Serial : DB-9 (9600/8n1, Xon/Xoff)Port
Environmental Specifications
Operating Temperature: 41 F – 95 F (5 – 35 C)
Storage temperature: -13 F – 158 F (-25C to 70C)
Relative Humidity: 10% - 90% (non-condensing)
Airflow CFM (Cubic Feet/Minute): 27 CFM
Airflow Direction: Front-to-Back
Electrical Power Specifications
Input Voltage
U.S.: 100 – 240 VAC switchable, 47 – 63 HZ
Europe: 208 – 265 VAC switchable, 47 – 63 HZ
AC Output Power: 400 watts
Input Voltage.: 100 – 240VAC
Input Frequency: 50 – 60 HZ
Input Current: 4A max at 230V
Inrush Current: 20A max at 230V
Power Factor: > 0.94/230V 50 Hz
Maximum Power Consumption: 400W
Heat Output (BTU/hour): 330 Maximum
DC Power Supply: -48v 450W GRND TERM, RING, VIN 12-10 AWG #10
Rated Input Voltage: -48VDC
Rated Input Current: 20A max at -36VDC, 10A max at -72VDC
Maximum Inrush Current: 100A 2u sec max
Maximum Heat Output (BTU/hour): 386 Maximum
Maximum Peak Power: 450W at -48V DC input
Installing the Infoblox 800 Series Appliance
Refer to the sections below to rack mount Infoblox 800 Series appliances, connect them to a power source, and cable it to a network. Before
proceeding, review the and follow the necessary precautions.Infoblox Safety Guide
