Introduction
Input/Output Connections
P110, IN112xa, IN114xa, IN116xa
Composite Video Input Connector1.
S-Video Input Connector2.
VGA-Out Connector (Monitor Loop-through Output)3.
VGA-IN/YPbPr Connector 4.
(PC Analog Signal/Component Video Input/HDTV/YPbPr)
HDMI2 Connector5.
USB Connector (Connect to PC for Remote Mouse func-6.
tion/USB Service for rmware upgrade)
Security Lock Slot7.
Audio2 Input 8. Connector (3.5mm mini jack)
Audio Output Connector ( 3.5mm mini jack)9.
Audio1 Input Connector (3.5mm mini jack)10.
RS-232 Connector (9-pin)11.
HDMI1 Connector12.
Power Socket13.
The interface is 
subject to model’s
specications.
7 9 10 11 12 138
2 3 4 51 6
