InFocus IN35 - Appendix; Projected Image Size

35
Appendix
Projected image size
NOTE: Visit our website for an interactive image size calculator.
Ta b l e 2:
Image sizes for XGA
Distance
to screen
(feet/m)
Minimum
Diagonal
(feet/m)
Maximum
Diagonal
(feet/m)
Minimum
Horizontal
(feet/m)
Maximum
Horizontal
(feet/m)
5/1.5 2.75/0.83 3.4/1.02 2.2/0.66 2.73/0.82
10/3 5.5/1.65 6.8/2.04 4.41/1.32 5.46/1.64
15/4.6 8.25/2.53 10.2/3.13 6.61/2.03 8.2/2.51
20/6.1 11/3.36 13.6/4.15 8.81/2.69 10.93/3.33
30/9.1 16.5/5.01 20.4/6.19 13.22/4.01 16.39/4.97
32.8/10 18.0/5.5 22.3/6.8 14.45/4.41 17.92/5.46
Ta b l e 3 :
Image sizes for WXGA
Distance
to screen
(feet/m)
Minimum
Diagonal
(feet/m)
Maximum
Diagonal
(feet/m)
Minimum
Horizontal
(feet/m)
Maximum
Horizontal
(feet/m)
5/1.5 2.55/.77 3.1/.93 2.18/.66 2.65/.79
10/3 5.1/1.53 6.2/1.86 4.37/1.31 5.29/1.59
15/4.6 7.65/2.35 9.3/2.85 6.55/2.01 7.94/2.43
20/6.1 10.2/3.11 12.4/3.78 8.73/2.66 10.58/3.23
30/9.1 15.3/4.64 18.6/5.64 13.1/3.97 15.87/4.81
32.8/10 16.73/5.1 20.34/6.2 14.32/4.37 17.35/5.29
