8
Menghubungkan catu daya
1.
Masukkan konektor kabel daya ke AC IN (AC
inlet) pada proyektor.
2.
Tancapkan dengan erat steker kabel daya
ke stopkontak listrik. Beberapa detik setelah
listrik terhubung, indikator POWER akan
terus menyala jingga.
Ingatlah bahwa bila fungsi AC POWER ON diaktifkan,
menghubungkan listrik akan menyebabkan proyektor
dihidupkan.
Menghidupkan proyektor
1.
Pastikan kabel daya telah terhubung dengan
erat dan benar ke proyektor dan stopkontak.
2.
Pastikan bahwa indikator POWER tetap
menyala jingga. Kemudian lepaskan
penutup lensa.
3.
Tekan tombol STANDBY/ON pada
proyektor atau kontrol jarak-jauh.
Lampu proyeksi akan menyala dan indikator
POWER akan mulai berkedip hijau. Bila
sudah benar-benar hidup, indikator akan
berhenti berkedip dan menjadi hijau terus.
STANDBY/ON SOURCE MENU
SECURITY
LAMP
TEMP
POWER
PERINGATAN Lebih berhati-hatilah saat menghubungkan kabel daya,
karena penyambungan yang tidak benar atau salah dapat menyebabkan
kebakaran dan/atau sengatan listrik.
Hanya gunakan kabel daya yang disertakan bersama proyektor. Jika sudah
rusak, konsultasikan dengan dealer untuk mendapatkan yang baru.
Hanya tancapkan kabel daya ke stopkontak dengan voltase yang sama.
Stopkontak listrik harus dekat dengan proyektor dan mudah diakses.
Lepaskan kabel daya untuk memutus sama sekali aliran listrik.
Jangan sekali-kali memodikasi kabel data.
PERINGATAN ►Cahaya kuat terpancar saat proyektor dihidupkan.
Jangan menatap lensa proyektor atau melihat bagian dalam proyektor melalui
lubang apa pun pada proyektor.
CATATAN • Hidupkan proyektor sebelum menghidupkan perangkat yang
terhubung.
Proyektor mempunyai fungsi AC POWER ON, yang dapat membuat proyektor
dihidupkan secara otomatis. Untuk informasi lebih lanjut, lihat Manual
Pengguna.
AC IN
Kabel
daya
Tombol STANDBY/ON
Indikator POWER

Other manuals for InFocus IN5122

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN5122 and is the answer not in the manual?

InFocus IN5122 Specifications

General IconGeneral
Matrix size0.63 \
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)2000:1
Screen size compatibility35.4 - 358 \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
FocusManual
Throw ratio1.5 - 2.5:1
Zoom capabilityYes
Focal length range- mm
Vertical lens shift range-20 - 0 °
Horizontal lens shift range-20 - 20 %
Lamp typeUHP
Lamp power245 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
3D-
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions1600 x 1200 (UXGA)
RMS rated power16 W
Number of built-in speakers2
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Ethernet LAN data rates10, 100 Mbit/s
Cables includedAC, RCA, VGA
Power consumption (standby)- W
Noise level32 dB
CertificationUL, c-UL, FCC, CE
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Cable lock slot typeKensington
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth318.5 mm
Width401 mm
Height111 mm
Weight4800 g
Package depth420 mm
Package width560 mm
Package height197 mm
Package weight8200 g
