InFocus IN5122 Network Guide

7
• The C:\Program Files\Projector
Tools\LiveViewer folder will be created and the
program will be installed into that folder. If you
wish to install to a different folder, click [Browse]
and select another folder.
NOTE
1. Connection to the network
8) Conrm the program folder name. If “Projector
Tools” is okay, press [Next] to continue. If not,
enter the desired folder name and then press
[Next].
1.2.2 Updating the “LiveViewer”
The latest version can be found at the InFocus Website:
http://www.infocus.com/support
Some features explained in this manual require “LiveViewer” Version 4.xx. (In the
version information a number between 00 and 99 will replace the xx.)
9)
Windows
®
XP: The Hardware Installation
dialog appears. Click [Continue Anyway].
Windows
®
Vista/7: The Windows Security
dialog will appear. Please click [Install this
driver software anyway] and continue
installation.
10) After a moment, installation will complete
and the Setup Complete dialog will appear
as shown on the right. Click [Finish]. This
completes the software installation. Your
computer will automatically restart.
(1) To conrm that the software has been
properly installed, press [Start] on the
toolbar, select All Programs and then
select the Projector Tools folder.
(2) The “LiveViewer” will appear in that folder
if the installation was successful.
1.2 Installing the “LiveViewer” (continued)
6) The License Agreement dialog appears. Select
“I accept the terms of the license agreement”
to accept the agreement and press [Next].
7) The Choose Destination Location dialog
appears. Press [Next].

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
