InFocus INF5520 - Specifications

Specifications Page 55
Specifications
To read the latest specifications on the Mondopad™ collaboration tablet, be sure to visit our
support website at www.infocus.com/support, as specifications are subject to change.
Size (viewable) 54.6” (138.7 cm diagonal)
Resolution 1920 x 1080
Refresh rate 60 Hz
Viewing angle ±89˚
Display colors 1.07G (10-bit)
Brightness 450 cd/m2 typical
Pixel pitch 0.63mm
Picture-in-Picture SBS/4 quadrant PIP
Video input compatibility Full NTSC, 480i, 480p, 720p, 1080i, 1080p/24, 1080p/30, 1080p/60
Data input compatibility VGA (640x480), SVGA (800x600), XGA (1024x768), SXGA
(1280x1024), SXGA+ (1400x1050), UXGA (1600x1200), WXGA+
(1440x900), WSXGA+ (1680x1050), WXGA (1280x800), WUXGA
(1920x1200)
Inputs USB 2.0 Type-A x 6, HDMI
®
1.3 x 2, VGA (HD15), Component, S-
Video, Composite, RS232 (DB9), RCA stereo (L/R) audio x 1, 3.5 mm
stereo mini-jack, USB B (for touch screen controller board), RJ45 x 2
Outputs RCA audio stereo (L/R) output for sound bar
Touch screen
‐ Multi -Touch touch screen system with support for 2 touch and
Windows
®
7 gesturing
‐ Glass protection overlay for LCD surface
‐ USB connection to PC from touch system panel board
Speakers (integrated) Stereo 7W x 2
Power AC 100-240V, 50-60Hz, 7.5A
Energy Star 5.2 for display and PC
Operating conditions 5° to 35°C at 0 to 10K ft
Noise <40dBA @ 25°C
Mount VESA standard 400mm x 400mm M6 screws
Dimensions (H x W x D) without
stand
32.4” (824mm) x 53.1” (1350mm) x 5.9” (151mm)
Weight (without stand) 114.2 lbs (51.8kg)
Shipping Weight 141.1 lbs (64kg)
Processor Intel
®
Core i5-2520m, QM67 chipset with support for AMT 7.1
Memory 4 GB
8 MB Flash memory, DDR3-1333
Hard Drive SATAII 320GB 5400RPM
LAN 802.3 10/100/1000 Base-T with Wake on LAN
Wi-Fi Dual band 802.11 a/b/g/n PCIe half mini card, 2.4 GHz with Intel AMT
support
Operating system Windows
®
7 Pro 64
