InFocus INF6521 User Manual

Page 24
PIP
Sel Adjust Enter Back Quit
< >
<
<
PIP
PIP MODE
PIP INPUT
PIP POSITION
PIP SWAP
PIP SIZE
PIP AUDIO
PIP RESET
NO
VGA
TOP-RIGHT
NO
SMALL
MAIN
NO
PIP Mode: enables or disables Picture-in-Picture mode. Options include: Yes and No.
PiP Input: selects the source input for the PiP window. Options include: VGA, component, video, HDMI1, HDMI2,
HDMI3, HDMI4, Mondopad.
PiP Position: moves the PiP window position. Options include: Top-right, Top-left, Bottom-right, Bottom-left.
PiP Swap: switches the source in the main and the PiP windows. Options include: Yes and No.
PIP Size: changes the size of the PiP window used in the Corner-to-Corner configuration. Options include: Small
(default), Middle and Large.
PIP Audio: switches the audio source from the main source to the PiP source. Options include: Main (default) and Sub.
PIP Reset: resets all PIP menu items to factory default settings. Options: Yes and No.
The PiP feature allows the user to display two distinct sources simultaneously on the monitor. These are the supported
combinations and configurations:
Input Video Component
(YPrPb)
VGA HDMI1 HDMI2 HDMI3 HDMI4 Mondopad
Video
      
Component
(YPrPb)
     
VGA
     
HDMI1
     
HDMI2
     
HDMI3
    
HDMI4
    
Mondopad
    
