Page 40
C
RJ45
RJ45
USB-A
USB-A
Antennas
LED
RS232
L
R
Audio
Audio OUT
IN 1
IN 2
HDMI
ANTENNAS
無線數據的接收和發射。
POWER
開啟/關閉主機。
HDMI OUT
將內部信號通過
HDMI
線纜輸出至另一台顯示器上。
USB-A
連接至
USB 3.0/2.0
硬碟機，數據傳輸。
RJ45
連接到乙太網絡
(10/100/1000 Mbps)
。
RS232
連接外部數據機。
MIC
連接至麥克風。
AUDIO IN1
接收來自外部裝置（例如
iPod
播放器）所發出的音頻訊號。
AUDIO IN2
接收來自外部裝置（例如
DVD
播放器）所發出的音頻訊號。
AUDIO OUT
連接到外接式立體聲喇叭。
41
43
Table of Contents
Table of Contents
3
Declaration of Conformity
5
Safety Considerations
6
安全資訊
7
Information about this Hardware Guide
8
What's Included
9
Setup
10
Mounting
10
Attaching the Speakers
11
Attaching the HD Video Conferencing Camera
12
Connecting to Other Devices
13
Connecting AC Power
16
External PC Touchscreen Control Setup
16
Turning the Monitor On/Off
16
Setting up the Wireless Mouse and Keyboard
17
Wireless Mouse
17
Wireless Keyboard
17
Using the Remote
18
Using the Keypad
21
OSD (On-Screen Display) Menu System
22
23
Screen
24
Audio
25
Pip
26
Configuration 1
27
Configuration 2
28
Advanced Option
29
Troubleshooting
30
Limited Warranty
33
安全注意事項
38
Mondopad 65"顯示器I/O Port 介紹前/後面板
40
